The frp filament winding equipment is arranged with a rotating mandrel, yarn feeding parts, resin bath, sand feeding area, and moving carriage. The carriage follows the set path while the mandrel turns at a planned speed. This helps fiber and sand sit in the right place. The control panel can set layers, winding angle, carriage travel, and speed. Space around the resin bath and sand area should stay open for cleaning and yarn change.
The frp filament winding equipment can include winding head, tailstock, trolley, resin bath, guide nozzle, yarn rack, sand feeder, tension device, electrical cabinet, and safety guards. Curing stations or extra mandrels can be added after drawing checking.
Product Parameters
|
Parameter |
Value |
|
Product diameter |
Φ300-Φ3000 mm |
|
Effective length |
12500 mm adjustable |
|
Winding angle |
50°-90° |
|
Yarn arrangement accuracy |
±1 mm |
|
Spinning speed |
≥73 m/min |
Product Advantages
1. The saved program helps repeated pipe orders keep a steady layer route.
2. Tension control helps the yarn stay neat while the carriage moves.
3. The modular parts make cleaning, moving, and later service easier.
Main Applications
The frp filament winding equipment can reduce hand lay-up work when pipe sizes repeat often.
FRP sand filled pipe lines for drainage, water transport, and underground pipe work.
Municipal pipe plants that need medium and large pipe sizes.
Workshops using resin, glass fiber, and quartz sand in one winding process.
Our Services
Service support includes drawing checking, layout discussion, test photos, videos, notes and wooden packing.
This equipment is useful when mould size, yarn path, sand feeding, and spare parts all need clear records. Parameter sheets, wiring records, and main parts lists can be kept for later service.
FAQ
Q: Can the diameter range be changed?
A: Yes. The mandrel size and frame travel should be checked before production.
Q: Can it run different fibers?
A: Glass fiber, carbon fiber, and basalt fiber can be discussed with the feeding system.
Q: How is the machine checked before delivery?
A: Test videos, photos, and basic running data can be prepared for checking.
