GRE Pipe Production Line
Your Professional GRE Pipe Production Line Supplier
Our goal is to be your reliable partner for GRE pipe production line in China. A new equipment manufacturing factory that focuses on the deep cultivation, manufacturing, and installation of winding equipment technology. We have a skilled engineering team dedicated to refining every stage, from product development and process improvement to production oversight, ensuring every product delivered meets rigorous quality and performance standards. The price is competitive and the product is quality-assured, which is a good choice for your long-term cooperation.
why choose us
Our R&D:
We have a strong R&D team, with close collaboration among our R&D, Mechanical, and Electrical Design departments to drive technological innovation and product upgrades.
Production and market:
Our equipment is highly sought after, with exports to over 20 countries and regions, including Thailand, Vietnam, Kazakhstan, and Russia.
Customized solutions:
We understand that every customer's needs are unique, so we can configure and manufacture equipment of various diameters and performance levels to meet your individual requirements.
Our services:
Our team of experts will recommend the most suitable products according to customer needs and provide detailed consultation, we ensure timely delivery, and we provide long-term service support.
High-performance products:
Precisely controlling fiber path and tension optimizes product mechanical properties (such as tensile strength, compressive strength, and fatigue resistance) to meet complex load requirements (such as lightweight and high-strength aerospace components).
Design flexibility:
Customizable product shapes (such as special-shaped pipes and conical tanks) can be achieved based on the core mold shape, and "structure-function integration" can be achieved by adjusting the winding angle and number of layers.
High production efficiency:
Automated cnc control reduces manual intervention, with winding speeds reaching 0.5-2 m/s. A single machine can produce tens of meters of pipe or hundreds of small products per day.
High material utilization:
Continuous fiber eliminates cutting waste, and the resin content is controllable (typically 15-35%), reducing raw material costs.
Corrosion and temperature resistance:
The use of high-performance resins (such as bismaleimide resin) imparts high-temperature and chemical resistance to products, making them suitable for use in extreme environments.
Specification of GRE Pipe Production Line
|
Product name |
GRE pipe production line |
|
Product diameter |
Ф10mm-Ф1000mm |
|
Product length |
≤6000mm |
|
Winding angle |
1°-89° |
|
Control system |
Four-axis linkage servo + industrial computer + CNCSYSTEM |
Features of GRE Pipe Production Line
CNC controlled winding machine:
The hoop and helical winding are available by computer program to meet different pressure ratings.
Inner curing:
Quick temperature rise realized by steam heating, quick reaction and curing of epoxy resin. Meanwhile, resin gathered at inner layer of pipe to form a resin rich layer, and the steel mold expansion by heat and pipe wrapping make it better performance of strength and leakage of inner layer of pipe.
CNC controlled temperature:
The temperature could be monitored and adjusted automatically for different stages and times.
Four mandrels:
Four mandrels rotating simultaneously, two mandrels for winding and another two for curing, which achieves high efficiency.
Application of GRE Pipe Production Line
Marine & offshore:
Suitable for applications like ballast piping, firewater systems, and cooling water systems on offshore platforms and ships.
Industrial:
Applied in industrial process piping, industrial waste water systems, and various plant piping needs.
Industrial:
Applied in industrial process piping, industrial waste water systems, and various plant piping needs.
GRE (Glassfiber Reinforced Epoxy) pipes are produced using the filament winding method, where continuous glass fiber rovings are impregnated with epoxy resin and wound onto a rotating mandrel to build the pipe's wall thickness.
After winding, the resin cures in an oven, and the mandrel is extracted. The pipes are then cut, machined at the ends, and undergo rigorous visual, dimensional, and hydrostatic testing before being ready for use.
Packing and Shipping of GRE Pipe Production Line
|
Packing |
Tray |
|
Shipping |
Shipped by road, sea, rail |
FAQ
Hengshui Mengshi Shengye FRP Equipment Co., Ltd. is one of the most professional GRE pipe production line manufacturers and suppliers in China. Welcome to buy high quality GRE pipe production line for sale here from our factory. For price consultation, contact us.
