Our Chemical Tank Winding Machines are used for FRP storage tanks, reaction tanks, transport tanks, and chemical vessels. The mandrel drive controls rotation, while the carriage places glass fiber along the tank body. The line is configured by tank diameter, product length, torque demand, resin system, and shell thickness requirement.
Product Parameters
|
Winding Diameter |
Selected according to tank diameter range |
|
Product Length |
Configured by tank length and workshop layout |
|
Drive Focus |
Mandrel rotation, carriage travel and tension control |
|
Resin System |
Matched to chemical storage or transport duty |
|
Optional Sections |
Curing station, edge trimming, mold release and inspection units |
|
Application |
FRP tank and chemical vessel production |
|
Production Capacity |
600 kg/h reference capacity |
|
Maximum Torque |
4500 N.m |
|
Control Mode |
Computer control, manual, semi-automatic, automatic |
Product Advantages
Chemical Tank Winding Machines keep mandrel speed and carriage travel coordinated, so the tank shell is easier to wind evenly.
The support frame helps hold long cylindrical tank molds during winding and reduces uneven fiber placement on large shells.
Resin wet-out and fiber feed can be arranged for corrosion-resistant tank wall structures used in chemical storage.
Main Applications
Chemical Tank Winding Machines are used for FRP chemical storage tanks, septic tanks, reaction tanks, transport vessels, dosing tanks and industrial containers.
FAQ
Q: Which tank production data should be confirmed?
A: Tank diameter, length, resin system, torque demand, and control mode should be confirmed.
Q: Can the machine make different tank types?
A: Yes. It can be configured for storage, reaction, septic or transport tank products.
Q: What affects tank shell uniformity?
A: Mandrel support, yarn tension, resin wet-out and carriage travel affect shell uniformity.
