The fiberglass filament winding machine works by turning the mandrel while a carriage guides wet fiber along a programmed path. Different models cover small samples and large pipe sections, so the frame size, tailstock distance, and support parts should match the mould. The resin bath needs steady wetting, and the guide eye should move without shaking. When a pipe has several layers, the program can change angle and speed by section. Good yarn tension helps the surface stay even and reduces loose fiber at the edge.
The fiberglass filament winding machine can include winding head, tailstock, moving carriage, resin bath, guide nozzle, yarn rack, tension device, electrical cabinet, and guards. Extra mandrels or curing support can be matched after size checking.
Product Parameters
|
Parameter |
Value |
|
Model JYFW-300 |
DN20-300 mm, L0.5-1.5 m |
|
Model JYFW-800 |
DN100-800 mm, L0.5-3.5 m |
|
Model JYFW-1200 |
DN100-1200 mm, L1-12 m |
|
Model JYFW-2500 |
DN300-2500 mm, L1-12 m |
|
Winding speed |
0.5-2 m/s |
Product Advantages
Several model ranges make it easier to match small and large pipe work.
CNC path control keeps the fiber route more stable between batches.
A clear frame layout helps cleaning, yarn change, and daily inspection.
Main Applications
1. Composite pipe production from DN20 samples to DN2500 sections.
2. Conical, straight, or special mandrel winding with changed carriage travel.
3. Lines that need controlled speed, layer count, and fiber path repeatability.
The fiberglass filament winding machine is also suitable when a workshop wants more stable results than manual wrapping.
FAQ
Q: Which model should be selected?
A: The pipe diameter, length, mould weight, and needed speed should be checked first.
Q: Can it wind shaped parts?
A: Yes. Conical or special shapes can be discussed when the mandrel drawing is clear.
Q: What information is needed before production?
A: Diameter, length, fiber type, resin process, and site layout are useful.
