The 3d filament winding machine places continuous fiber around a rotating mandrel while the guide system follows a set route. The path can be adjusted for hoop layers, cross layers and local strengthening areas. The machine is useful for epoxy resin work because the fiber must sit cleanly before curing. The resin bath keeps the yarn wet, and the guide nozzle helps the fiber land in the planned position. During first-piece checking, operators can slow the movement, look at the overlap and then save a better setting for later use. This makes the machine suitable for products that are not easy to finish with simple manual wrapping.
Main parts include a winding head, mandrel support, moving carriage, resin bath, fiber creel, tension device, guide nozzle, control cabinet and safety cover. Curing stands or extra mandrels can be added when the product plan needs them.
Product Parameters
|
Parameter |
Value |
|
Product type |
GRE and epoxy FRP pipe |
|
Winding route |
Multi-angle program path |
|
Control mode |
Computer program setting |
|
Layer setting |
Adjustable by product design |
|
Typical output |
Pipe and composite pressure parts |
Product Advantages
1. The 3d filament winding machine can follow a more flexible route than a basic winding line.
2. Layer data can be saved, checked and changed for test batches.
3. Fiber tension is easier to control during long winding work.
Main Applications
GRE pipe and epoxy FRP pipe production.
Composite pressure parts with several fiber directions.
Trial work for new mandrel shapes and layer plans.
Products needing extra winding around ends or stress areas.
Our Services
Support can include mandrel data checking, sample route discussion, trial photos, packing marks and basic notes for daily operation.
For the 3d filament winding machine, checking starts from product shape, winding route, resin type and support length, so the selected line can match the real part instead of only the machine name.
FAQ
Q: Is this machine only for round pipe?
A: No. It can be discussed for special mandrels when the path is suitable.
